FLOWLINE LU10 Ultrasonic Liquid Level Switch
Submersible PP or PFA Teflon® sensor and cable for corrosive liquids
60VA SPST relay selectable NO or NC via power supply wiring polarity
Compatible with Smart Trak and Switch-Pak installation fittings
|
Series |
LU10 |
|
Type |
Ultrasonic switch |
|
Classification |
Intrinsically safe |
|
Application |
Chemical |
|
Function |
Level switch |
|
Max. length |
— |
|
Supply |
12-36 VDC |
|
Contact |
(1) SPST relay |
|
Rating |
32 VDC (0.5A max) |
|
Enclosure |
NEMA 6 (IP68) |
|
Termination |
Cable |
|
Mount |
3/4″ NPT (G) |
|
Temperature |
-40º F. (-40º C.) to 176º F. (80º C.) |
|
Max. pressure |
150 PSI (10 bar) |
|
Material |
PP / PFA |
lCSA approved intrinsically safe for use in hazardous environments
lSubmersible PP or PFA Teflon® sensor and cable for corrosive liquids
l60VA SPST relay selectable NO or NC via power supply wiring polarity
lCompatible with Smart Trak and Switch-Pak installation fittings
