IM3533

IM3533-01

Measurement modes

LCR (Measurement with single condition), Transformer testing (N, M, ΔL), Continuous testing(Continuous measurement under saved conditions) (LCR mode)

LCR (Measurement with single condition), Transformer testing (N, M, ΔL), Analyzer (sweep testing), Continuous Testing (LCR/Analyzer mode)

Measurement parameters

Z, Y, θ, X, G, B, Q, Rdc (DC resistance), Rs (ESR), Rp, Ls, Lp, Cs, Cp, D (tanδ), N, M, ΔL, T

Measurement range

100 mΩ to 100 MΩ, 10 ranges (All parameters defined in terms of Z.)

Displayable range

Z, Y, Rs, Rp, Rdc, X, G, B, Ls, Lp, Cs, Cp : ± (0.00000 [unit] to 9.99999G [unit]) Real value display for Z and Y only

θ: ± (0.000° to 180.000°), D: ± (0.00000 to 9.99999)

Q: ± (0.00 to 99999.9), Δ%: ± (0.0000% to 999.999%), T: -10.0°C to 99.9°C

Basic accuracy

Z : ±0.05% rdg. θ: ±0.03°

Measurement frequency

1 mHz to 200 kHz (5 digits setting resolution, minimum resolution 1 mHz)

Measurement signal level

[Normal mode]

V mode, CV mode: 5 mV to 5 Vrms, 1 mVrms steps

CC mode: 10 μA to 50 mArms, 10 μArms steps

[Low impedance high accuracy mode]

V mode, CV mode: 5 mV to 2.5 Vrms, 1 mVrms steps

CC mode: 10 μA to 100 mArms, 10 μArms steps

Output impedance

Normal mode: 100 Ω, Low impedance high accuracy mode: 25 Ω

Display

5.7-inch touch-screen color TFT, display can be set to ON/OFF

Measurement time

2 ms (1 kHz, FAST, display OFF, representative value)

Functions

DC bias measurement, DC resistance temperature compensation (converted reference temperature display), Comparator, BIN measurement (classify function), Panel loading/saving, Memory function

Interfaces

EXT I/O (Handler), USB communication (high-speed), USB memory

Optional: Choose 1 from RS-232C, GP-IB, or LAN

Power supply

100 to 240 V AC, 50/60 Hz, 50 VA max

Dimensions and mass

330 mm (12.99 in) W × 119 mm (4.69 in) H × 168 mm (6.61 in) D, 3.1 kg (109.3 oz)

Accessories

Power cord × 1, Instruction manual × 1, CD-R (Includes PC commands and sample software) × 1
