HIOKI IR4016-20/IR4017-20/IR4018-20 Analog Insulation Tester, Megohmmeter
IR4017-20 : Single range testing voltage of 500 V
IR4018-20 : Single range testing voltage of 1000 V
|
Model |
IR4016-20 |
IR4017-20 |
IR4018-20 |
|
Rated output voltage |
500 V DC |
500 V DC |
1000 V DC |
|
Effective maximum indicated value |
100 MΩ |
1000 MΩ |
2000 MΩ |
|
Accuracy 1st effective measuring range |
±5 % of indicated value 0.1 to 50 MΩ |
±5 % of indicated value 1 to 500 MΩ |
±5 % of indicated value 2 to 1000 MΩ |
|
Lower limit resistance |
0.5 MΩ (measurement resistance value to maintain testing voltage) |
0.5 MΩ (measurement resistance value to maintain testing voltage) |
1 MΩ (measurement resistance value to maintain testing voltage) |
|
Overload protection |
600 V AC (10 sec.) |
600 V AC (10 sec.) |
1200 V AC (10 sec.) |
|
AC voltage range |
0 to 600 V (50/60 Hz), ±5 % of maximum scale value accuracy, 500 kΩ or more input resistance |
0 to 600 V (50/60 Hz), ±5 % of maximum scale value accuracy, 500 kΩ or more input resistance |
0 to 600 V (50/60 Hz), ±5 % of maximum scale value accuracy, 500 kΩ or more input resistance |
|
Other functions |
Bright LED luminous scale, Drop proof (on concrete, 1 m/1 time), Battery check, Live circuit check, Auto discharge |
Bright LED luminous scale, Drop proof (on concrete, 1 m/1 time), Battery check, Live circuit check, Auto discharge |
Bright LED luminous scale, Drop proof (on concrete, 1 m/1 time), Battery check, Live circuit check, Auto discharge |
|
Power supply |
LR6 (AA) alkaline batteries ×4, Continuous use: 20 hours (no load) |
LR6 (AA) alkaline batteries ×4, Continuous use: 20 hours (no load) |
LR6 (AA) alkaline batteries ×4, Continuous use: 20 hours (no load) |
|
Dimensions and mass |
159 mm (6.26 in) W × 177 mm (6.97 in) H × 53 mm (2.09 in) D, 610 g (21.5 oz), (including battery, excluding test lead) |
159 mm (6.26 in) W × 177 mm (6.97 in) H × 53 mm (2.09 in) D, 610 g (21.5 oz), (including battery, excluding test lead) |
159 mm (6.26 in) W × 177 mm (6.97 in) H × 53 mm (2.09 in) D, 610 g (21.5 oz), (including battery, excluding test lead) |
|
Accessories |
Test Lead L9787 ×1, LR6 (AA) alkaline batteries ×4, Instruction manual ×1, Shoulder strap ×1 |
Test Lead L9787 ×1, LR6 (AA) alkaline batteries ×4, Instruction manual ×1, Shoulder strap ×1 |
Test Lead L9787 ×1, LR6 (AA) alkaline batteries ×4, Instruction manual ×1, Shoulder strap ×1 |
• IR4016-20 : Single range testing voltage of 500 V
IR4017-20 : Single range testing voltage of 500 V
IR4018-20 : Single range testing voltage of 1000 V
• Test insulation resistance up to 100 MΩ
• Built tough to withstand a 1-meter drop onto a concrete floor
• Bright LED luminous scale
• Check for live circuits and battery status
• Integrated hard case for quick and easy storage without disconnecting the leads
