Pressmaster KHA 0760 Crimping Tool
KHA-0760 is crimping tool for insulated
heat shrink connectors, 0.5 - 6.0 mm²/AWG 22- 10 (red, blue, yellow),
Oval-Crimp symetric.
|
Length |
256 mm/10.08" |
|
Width |
22 mm/0.87" |
|
Height |
80 mm/3.15" |
|
Weight |
550 gr/1.21 lb |
|
Wire size |
0.5-6 mm² / AWG 22- AWG 10 |
|
Crimp dimensions mm/ mm² |
0,50 - 1,5 mm²/1,5 - 2,5 mm²/4 - 6 mm² |
|
Crimp dimensions inch/AWG |
AWG 22 - AWG 16/AWG 16 – AWG 14/AWG 12 - AWG 10 |
|
Connector |
Heat shrink connectors |
|
Description: |
For pre insulated red,blue and yellow heat shrink connectors. |
|
Life span, cycles |
50,000 |
lHigh strength, through hardened alloy steel construction
lUnique mechanism significantly reduces hand force requirement over competing crimping tools
lVersatile and easy to customize for right hand or left hand users.
lNon-slip pad holds tool in place when leveraging on a work surface
lFull cycle crimp mechanism to ensure consistent, reliable crimp
lRatchet release mechanism to clear miscrimps and obstructions
lPrecision eccentric adjustment for consistent performance and ability to calibrate
lHole in handle allows attachment of safety strap
lEach tool has a unique serial number for traceability.
