Pressmaster Mobile die set/4300-3141/AAA
Mobile die set for coaxial-/Fiberoptic: ST,
SC, SMA, SMB, SFR. This is one of the interchangeable crimp die sets for the
MCT frame. A wide range of crimp dies enables the user to cover all
applications in just one tool frame.
|
Length |
34 mm/1.34" |
|
Width |
10 mm/0.39" |
|
Height |
39 mm/1.54" |
|
Weight |
76 gr/0.17 lb |
|
Crimp dimensions mm/mm² |
3.25 mm HEX/3.84 mm HEX/4.52 mm HEX/5.41 mm HEX |
|
Crimp dimensions inch/AWG |
0.128'/0.151'/0.178'/0.213' |
|
Connector: |
Fiberoptic |
|
Description |
For example ST, SC, SMA, SMB, SFR. |
|
Life span, cycles |
20,000 |
lReliable – crimping performance is consistent and accurate with a parallel action stroke.
lEasy to use – designed to give the user full visibility of the crimping process. Handles are shaped for low effort crimping with a one or two hand grip.
lVersatile – an easy-access release function allows fast and simple exchange of crimp dies. No special tools needed.
lWeight and size of the tool are optimized to make it easy to carry. Dies are kept in pairs and delivered in a modular reusable box.
lComfortable – the entire tool frame is covered in smooth plastic for comfortable use, also for outdoor operations in all weather conditions
lHole in handle allows attachment of safety strap.
