Pressmaster KTV 6810 Crimping Tool
KTV-6810 is a crimping tool for CATV
connectors, 8.23 mm, 9.70 mm, 6.65 mm/.262', .324', .381', HEX-Crimp.
|
Length |
256 mm/10.08" |
|
Width |
22 mm/0.87" |
|
Height |
80 mm/3.15" |
|
Weight |
560 gr/1.23 lb |
|
Crimp dimensions mm/mm² |
6,65 mm/8,23 mm/9,70 mm |
|
Crimp dimensions inch/AWG |
.262'/.324'/.381' |
|
Connector |
CATV connector |
|
Description |
For CATV connectors. |
|
Life span, cycles |
50,000 |
|
Cables |
1695, RG143A/U, RG212/U, RG222/U, RG6 Quad, RG6A/U, TWINAX |
lHigh strength, through hardened alloy steel construction
lUnique mechanism significantly reduces hand force requirement over competing crimping tools
lVersatile and easy to customize for right hand or left hand users.
lNon-slip pad holds tool in place when leveraging on a work surface
lFull cycle crimp mechanism to ensure consistent, reliable crimp
lRatchet release mechanism to clear miscrimps andobstructions
lPrecision eccentric adjustment for consistent performance and ability to calibrate
lHole in handle allows attachment of safety strap
lEach tool has a unique serial number for traceability
