FLOWLINE LR41 Radar Solids Level Sensor
Rugged 316L stainless steel antenna and process mount
Configuration via push button display or HART communicator
Gimbal flange for easy positioning with the angle of repose
Configuration via push button display or HART communicator
Gimbal flange for easy positioning with the angle of repose
Model :
LR41
|
Classification |
Intrinsically safe |
|
Media |
Solids |
|
Application |
Crusher, transfer station, stockpile, silo, bin |
|
Process dust |
Moderate |
|
Range |
229.7' (70m) |
|
Output |
4-20 mA, HART |
|
Installation |
Bracket or gimbal flange |
|
Mount |
1 1/2" NPT, 4" or 5" ANSI |
|
Max. temperature |
752º F. (400º C.) |
|
Antenna type |
4" or 5" horn |
|
Ant. air purge |
Yes |
|
Ant. dust shield |
Option |
|
Ant. material |
316L with optional PTFE dust shield |
- Rugged 316L stainless steel antenna and process mount
- Configuration via push button display or HART communicator
- Gimbal flange for easy positioning with the angle of repose
- Antenna air-purge for use with significant dust conditions
- LCD displays level in feet or meters with percent of span bar
- Optional display mode indicates the echo signal return curve
- Fail-safe diagnostics with selectable signal fail-safe outputs
- PTFE antenna cover for use with moderate dust conditions
- Recognition, storage and rejection of false echo signal returns
- IP67 stainless enclosure with polycarbonate display window
