Pressmaster CCC 2511 Crimping tool
CCC-2511 is a crimping tool for coaxial
connectors,10.9 mm, 5.41 mm, 2.54 mm, 1.69 mm/.213",
.429",.100", .067", HEX-Crimp.
|
Length |
230 mm/9.06" |
|
Width |
21 mm/0.83" |
|
Height |
70 mm/2.76 " |
|
Weight |
540 gr/1.19 lb |
|
Crimp dimensions mm/mm² |
5,41/10,90 mm/2,54 mm/1,69 mm |
|
Crimp dimensions inch/AWG |
.213/.429/.100/.067 |
|
Connector |
Coaxial connector |
|
Description |
For example BNC, TNC, N connectors on RG 58, RG 8, RG 11, Ethernet, Thinnet. |
|
Life span, cycles |
50,000 |
|
Cables |
9914, RG114A/U, RG115A/U, RG12A/U, RG133A/U, RG142B/U, RG144/U, RG165/U, RG166/U, RG1A/U, RG213/U, RG214/U, RG215/U, RG216/U, RG22/U, RG223/U, RG225/U, RG227/U, RG22B/U, RG26A/U, RG302/U, RG391/U, RG58C/U, RG63B/U, RG65A/U, RG79B/U |
lHigh strength, through hardened alloy steel construction
lVersatile and easy to customize for right hand or left hand users
lFull cycle crimp mechanism to ensure consistent, reliable crimp
lRatchet release mechanism to clear miscrimps and obstructions
lPrecision eccentric adjustment for consistent performance and ability to calibrate
lEach tool has a unique serial number for traceability
