Pressmaster KRF 1025S Crimping Tool
KRF-1025S is a crimping tool for right
angeled uninsulated connectors, 1.0 - 2.5 mm²/AWG 18 - 14, B/F-Crimp.
|
Length |
204 mm/8.03" |
|
Width |
22 mm/0.87" |
|
Height |
76 mm/2.99" |
|
Weight |
560 gr/1.23 lb |
|
Wire size |
1-2.5 mm² / AWG 18- AWG 14 |
|
Crimp dimensions mm/ mm² |
1,0 - 2,5 mm² |
|
Crimp dimensions inch/AWG |
AWG 18 - 14 |
|
Connector |
Uninsulated 90° angeled open barrel connectors |
|
Description |
For uninsulated angeled open barrel cannoectors. |
|
Life span, cycles |
50,000 |
lHigh strength, through hardened alloy steel construction
lUnique mechanism significantly reduces hand force requirement over competing crimping tools
lVersatile and easy to customize for right hand or left hand users.
lNon-slip pad holds tool in place when leveraging on a work surface
lFull cycle crimp mechanism to ensure consistent, reliable crimp
lRatchet release mechanism to clear miscrimps and obstructions
lPrecision eccentric adjustment for consistent performance and ability to calibrate
lHole in handle allows attachment of safety strap
lEach tool has a unique serial number for traceability
