Standards

DIN 5032-7: 1985 class B, JIS C 1609-1: 2006 general AA class

Light receiving element

Silicon photo diode

Range selection

Auto/ Manual

Linearity

±2% rdg. (Multiply by 1.5 for display values in excess of 3000 lx.)

Accuracy guarantee for temperature and humidity

21 °C to 27 °C (69.8 °F to 80.6 °F), 75% rh or less (non-condensing)

Response time

Auto range: within 5 seconds, Manual range: within 2 seconds

D/A output

Output level: 2 V/range f.s. (2.5 V is output when the range f.s. is exceeded.)

Output accuracy: ±1% rdg. ±5 mV (at display count)

Functions

Timer hold function, Memory function (Up to 99 measured data can be saved.), Hold, Auto power off function, Buzzer sound, Backlight, Zero adjustment

Power supply

LR6 Alkaline battery ×2 (continuous use 300 hours), Max. rated power 500 mVA, or R6 Manganese battery ×2, or USB bus power (5 VDC)

Dimensions and mass

78 mm (3.07 in)W × 170 mm (6.69 in)H × 39 mm (1.54 in)D, 310 g (10.9 oz) (including the batteries)

Accessories

Instruction Manual ×1, LR6 Alkaline battery ×2, Sensor cap (with strap) ×1, Carrying case (soft) ×1, Strap (for instrument) ×1, USB cable (0.9 m/2.95 ft) ×1, CD (USB driver, dedicated computer application software, and communications specifications) ×1
