Measurement lines

Single-phase 2-wires

Measurement items

Voltage, Current, Active power, Apparent power, Power factor

Measurement range

[Voltage] 200 V AC (300 V Max.)

[Current] 50/ 200/ 500 mA, 2/ 5/ 20 A AC (30 A Max.)

[Power] 10.000 W to 4.000 kW (combination of voltage and current ranges)

Input resistance (50/60 Hz)

[Voltage] 2.4 MΩ, [Current] 7 mΩ or less (direct input)

Basic accuracy

[Guaranteed for 1 year, Voltage, Current, Active power] ±0.1 % rdg. ±0.1 % f.s. (45 Hz to 66 Hz, input current 20 A or less)

[Guaranteed for 3 years, Voltage, Current, Active power] ±0.1 % rdg. ±0.2 % f.s. (45 Hz to 66 Hz, input current 20 A or less)

Display refresh rate

5 times/s

Frequency characteristics

45 Hz to 5 kHz

D/A output

3 channels outputs simultaneously for voltage, current, active power

+2 V DC f.s.

Functions

Scaling (VT, CT ratio settings), Average function

Interfaces

RS-232C standard, GP-IB (Model 3333-01 only)

Power supply

100 to 240 V AC, 50/60 Hz, 20 VA max.

Dimensions and mass

160 mm (6.30 in) W × 100 mm (3.94 in) H × 227 mm (8.94 in) D, 1.9 kg (67.0 oz)

Accessories

Instruction manual ×1, Power cord ×1
