Pressmaster DRB 0805 HD Crimping tool
DRB-0805 HD is a crimping tool for D-Sub
connectors, High-Density, 0.08 - 0.50 mm²/ 28-20 AWG, B-Crimp, with locator.
|
Length |
198 mm/7.8" |
|
Width |
18 mm/0.71" |
|
Height |
59 mm/2.32" |
|
Weight |
451 gr/0.99 lb |
|
Wire size |
0.08-0.5 mm² / AWG 28- AWG 20 |
|
Crimp dimensions mm/mm² |
0.08 - 0.22 mm² (1/2D)/0.08 - 0.22 mm²/0.22 - 0.50 mm² |
|
Crimp dimensions inch/AWG |
AWG 28 - AWG 24/AWG 28 – AWG 24/AWG 24 - AWG 20 |
|
Connector |
D-Sub High Density connector |
|
Description |
Open barrel/Uninsulated D-Sub pins , high density only, standard type |
|
Life span, cycles |
50,000 |
lHigh strength, through hardened alloy steel construction
lVersatile and easy to customize for right hand or left hand users
lFull cycle crimp mechanism to ensure consistent, reliable crimp
lRatchet release mechanism to clear miscrimps and obstructions
lPrecision eccentric adjustment for consistent performance and ability to calibrate
lEach tool has a unique serial number for traceability
