Pressmaster CSA 0760 Crimping tool
CSA-0760 is a crimping tool for insulated
connectors, 0.75 - 6.0 mm²/AWG 22-10 (red, blue, yellow), Oval- Crimp
symmetric.
|
Length |
225 mm/8.86" |
|
Width |
21 mm/0.83" |
|
Height |
70 mm/2.76" |
|
Weight |
540 gr/1.19 lb |
|
Wire size |
0.75-6 mm² / AWG 22- AWG 10 |
|
Crimp dimensions mm/mm² |
0,75 - 1,5 mm² (red)/1,5 - 2,5 mm²(blue)/4 - 6 mm² (yellow) |
|
Crimp dimensions inch/AWG |
AWG 22 - AWG 16/AWG 16 – AWG 14/AWG 12 - AWG 10 |
|
Connector |
Insulated connectors |
|
Description |
For pre insulated red, blue and yellow connectors. |
|
Life span, cycles |
50,000 |
lHigh strength, through hardened alloy steel construction
lVersatile and easy to customize for right hand or left hand users
lFull cycle crimp mechanism to ensure consistent, reliable crimp
lRatchet release mechanism to clear miscrimps and obstructions
lPrecision eccentric adjustment for consistent performance and ability to calibrate
lEach tool has a unique serial number for traceability
