Pressmaster CFO 5432 Crimping tool
CFO-5432 is a crimping tool for fiber optic
connectors, 3.25 mm, 3.84 mm, 5.41 mm, 5.00 mm, 4.52 mm/.128", .151",
.213", .197", .178", HEX-Crimp. ST, SC, SMA, SMB, SFR.
|
Length |
230 mm/9.06" |
|
Width |
21 mm/0.83" |
|
Height |
70 mm/2.76" |
|
Weight |
540 gr/1.19 lb |
|
Crimp dimensions mm/mm² |
3,25 mm/3,84 mm/5,41 mm/5,00 mm/4,52 mm |
|
Crimp dimensions inch/AWG |
.128/.151/.213/.197/.178 |
|
Connector |
Fiber optic |
|
Description |
For example SMA, SMB, SFR, ST, SC. Life span, cycles: 50,000 |
lHigh strength, through hardened alloy steel construction
lVersatile and easy to customize for right hand or left hand users
lFull cycle crimp mechanism to ensure consistent, reliable crimp
lRatchet release mechanism to clear miscrimps and obstructions
lPrecision eccentric adjustment for consistent performance and ability to calibrate
lEach tool has a unique serial number for traceability
