HIOKI CM3289 AC Clamp Meter
• New redesigned sensor for even easier clamping (CM3289)
• Expanded -25 °C to 65 °C operating temperature range
|
AC Current range |
42.00 to 1000 A, 3 ranges (40 Hz to 1 kHz, True RMS), Basic accuracy: ±1.5 % rdg. ±5 dgt. |
|
DC Voltage range |
420.0 mV to 600 V, 5 ranges, Basic accuracy: ±1.0 % rdg. ±3 dgt. |
|
AC Voltage range |
4.200 V to 600 V, 4 ranges (45 to 500 Hz, True RMS), Basic accuracy: ±1.8 % rdg. ±7 dgt. |
|
Crest factor |
2.5 or less at 2500 counts (Linearly decreases to 1.5 or less at 4200 count) |
|
Resistance range |
420.0 Ω to 42.00 MΩ, 6 ranges, Basic accuracy: ±2 % rdg. ±4 dgt. |
|
Other functions |
Continuity: Buzzer sounds at 50 Ω ±40 Ω or less, Data hold, Auto power save, Drop-proof from height of 1 meter |
|
Display |
LCD, max. 4199 dgt., Display refresh rate: 400 ms |
|
Power supply |
Continuous use 70 hours |
|
Core jaw dia. |
φ 33 mm (1.30 in) |
|
Dimensions and mass |
57 mm (2.24 in) W × 181 mm (7.13 in) H × 16 mm (0.63 in) D, 100 g (3.5 oz) |
|
Accessories |
CARRYING CASE 9398 × 1, TEST LEAD L9208 × 1, Coin type lithium battery (CR2032) × 1, Instruction manual × 1 |
• The CM3289 is the successor to the popular 3280-20F with a redesigned thinner sensor to help you get into the tightest spaces.
• New redesigned sensor for even easier clamping (CM3289)
• Expanded -25 °C to 65 °C operating temperature range
• Model CM3289: Measure even harmonic waveform components using the True RMS method
• Model 3280-10F: Measure the fundamental waveform component using the average rectified method
• Connect the CT6280 flexible sensor to measure up to 4199 A in thick or paired wires
