CT9667-01

CT9667-02

CT9667-03

Rated input current

5000 A AC/ 500 A AC

5000 A AC/ 500 A AC

5000 A AC/ 500 A AC

Max. allowable input

10000 A continuous (45 to 66 Hz, requires derating at frequency)

10000 A continuous (45 to 66 Hz, requires derating at frequency)

10000 A continuous (45 to 66 Hz, requires derating at frequency)

Bandwidth

10 Hz to 20 kHz (±3dB)

10 Hz to 20 kHz (±3dB)

10 Hz to 20 kHz (±3dB)

Amplitude and phase accuracy

±2 % rdg. ±0.3 % f.s. (45 to 66 Hz, at center of flexible loop)

Phase: ±1 deg (45 to 66 Hz)

±2 % rdg. ±0.3 % f.s. (45 to 66 Hz, at center of flexible loop)

Phase: ±1 deg (45 to 66 Hz)

±2 % rdg. ±0.3 % f.s. (45 to 66 Hz, at center of flexible loop)

Phase: ±1 deg (45 to 66 Hz)

Output voltage

500 mV AC/f.s. (0.1 mV AC/A) at 5000 A range

500 mV AC/f.s. (1 mV AC/A) at 500 A range

500 mV AC/f.s. (0.1 mV AC/A) at 5000 A range

500 mV AC/f.s. (1 mV AC/A) at 500 A range

500 mV AC/f.s. (0.1 mV AC/A) at 5000 A range

500 mV AC/f.s. (1 mV AC/A) at 500 A range

Max. rated voltage to earth

1000 V AC (CAT III), 600 V AC (CAT IV)

1000 V AC (CAT III), 600 V AC (CAT IV)

1000 V AC (CAT III), 600 V AC (CAT IV)

Core diameter

φ 100 mm (3.94 in)

φ 180 mm (7.09 in)

φ 254 mm (10.00 in)

Output terminal

BNC

BNC

BNC

Operating temperature

-25 °C to +65 °C

(-13 °F to 149 °F)

-25 °C to +65 °C

(-13 °F to 149 °F)

-10 °C to +50 °C

(14 °F to 122 °F)

Power supply

LR6 (AA) alkaline batteries ×2, Continuous use : 7 days (rated power 35 mVA), or AC adapter 9445-02/-03 (rated power 0.2 VA), or External power supply 5 to 15 V DC (rated power 0.2 VA)

LR6 (AA) alkaline batteries ×2, Continuous use : 7 days (rated power 35 mVA), or AC adapter 9445-02/-03 (rated power 0.2 VA), or External power supply 5 to 15 V DC (rated power 0.2 VA)

LR6 (AA) alkaline batteries ×2, Continuous use : 7 days (rated power 35 mVA), or AC adapter 9445-02/-03 (rated power 0.2 VA), or External power supply 5 to 15 V DC (rated power 0.2 VA)

Dust and water resistance

Flexible loop only: IP54

* Do not use when wet.

Flexible loop only: IP54

* Do not use when wet.

N/A

Dimensions and mass

Flexible loop cable diameter: φ7.4 mm (0.29 in),

Cable length: Between flexible loop and battery box: 2 m (6.56 ft),

Output cable: 1 m (3.28 ft), Battery box: 35 mm (1.38 in)W × 120.5 mm (4.74 in)H × 34 mm (1.34 in)D, 280 g (9.9 oz)

Flexible loop cable diameter: φ7.4 mm (0.29 in),

Cable length: Between flexible loop and battery box: 2 m (6.56 ft),

Output cable: 1 m (3.28 ft), Battery box: 35 mm (1.38 in)W × 120.5 mm (4.74 in)H × 34 mm (1.34 in)D, 280 g (9.9 oz)

Flexible loop cable diameter: φ13 mm (0.51 in), Cable length: Between flexible loop and battery box: 2 m (6.56 ft), Output cable: 1 m (3.28 ft)

Battery box: 35 mm (1.38 in)W × 120.5 mm (4.74 in)H × 34 mm (1.34 in)D, 470 g (16.6 oz)

Accessories

LR6 (AA) alkaline batteries ×2, Instruction manual ×1

LR6 (AA) alkaline batteries ×2, Instruction manual ×1

LR6 (AA) alkaline batteries ×2, Instruction manual ×1
