FLOWLINE LR26 Radar Liquid Level Sensor
316L antenna with PTFE inner shield for corrosive media
Configuration via push button display or HART communicator
6.3 GHz. pulse radar is unaffected by most foam and agitation
Configuration via push button display or HART communicator
6.3 GHz. pulse radar is unaffected by most foam and agitation
Model :
LR26
|
Classification |
Intrinsically safe |
|
Media |
Liquids |
|
Application |
Process |
|
Process condition |
Extreme |
|
Tank location and material |
Above grade metal or below grade in any tank material |
|
Corrosive |
Yes |
|
Range |
114.8' (35m) |
|
Output |
4-20 mA |
|
Installation |
Flange |
|
Mount |
4", 6" ANSI |
|
Max. temperature |
266º F. (130º C.) |
|
Max. pressure |
580 PSI (40 bar) |
|
Ant. material |
316L & PTFE |
- 316L antenna with PTFE inner shield for corrosive media
- Configuration via push button display or HART communicator
- 6.3 GHz. pulse radar is unaffected by most foam and agitation
- 12” (30cm) dead band enables utilization of the entire tank
- LCD displays level in feet or meters with percent of span bar
- Optional display mode indicates the echo signal return curve
- Auto-temperature compensation for accurate measurement
- Fail-safe diagnostics with selectable signal fail-safe outputs
- Recognition, storage and rejection of false echo signal returns
- IP67 stainless enclosure with polycarbonate display window
