FLOWLINE LR25 Radar Liquid Level Sensor
316L antenna with PTFE inner shield for corrosive media
Simple configuration via integral push button display module
6.3 GHz. pulse radar is unaffected by most foam and agitation
Simple configuration via integral push button display module
6.3 GHz. pulse radar is unaffected by most foam and agitation
Model :
LR25
|
Classification |
General purpose |
|
Media |
Liquids |
|
Application |
Process |
|
Process condition |
Extreme |
|
Tank location and material |
Above grade metal or below grade in any tank material |
|
Corrosive |
Yes |
|
Range |
114.8' (35m) |
|
Output |
4-20 mA |
|
Installation |
Flange |
|
Mount |
4", 6" ANSI |
|
Max. temperature |
266º F. (130º C.) |
|
Max. pressure |
580 PSI (40 bar) |
|
Ant. material |
316L & PTFE |
- 316L antenna with PTFE inner shield for corrosive media
- Simple configuration via integral push button display module
- 6.3 GHz. pulse radar is unaffected by most foam and agitation
- 12” (30cm) dead band enables utilization of the entire tank
- LCD displays level in feet or meters with percent of span bar
- Optional display mode indicates the echo signal return curve
- Fail-safe diagnostics with selectable signal fail-safe outputs
- Recognition, storage and rejection of false echo signal returns
- Rugged IP67 aluminum enclosure with polycarbonate window
