FLOWLINE LR10 Radar Liquid Level Sensor
PFA encapsulated antenna and mount for corrosive media
Configuration via push button display or HART communicator
26 GHz. pulse radar is unaffected by vapor or condensation
Configuration via push button display or HART communicator
26 GHz. pulse radar is unaffected by vapor or condensation
Model :
LR10
|
Classification |
General purpose |
|
Media |
Liquids |
|
Application |
Storage |
|
Process condition |
Easy |
|
Tank location and material |
Above grade metal or below grade in any tank material |
|
Corrosive |
Yes |
|
Range |
32.8' (10m) |
|
Output |
4-20 mA |
|
Installation |
Tank adapter or flange |
|
Mount |
1 1/2" NPT |
|
Max. temperature |
266° F. (130°C.) |
|
Max. pressure |
43.5 PSI (3 bar) |
|
Ant. material |
PFA |
- PFA encapsulated antenna and mount for corrosive media
- Configuration via push button display or HART communicator
- 26 GHz. pulse radar is unaffected by vapor or condensation
- 12” (30cm) dead band enables utilization of the entire tank
- LCD displays level in feet or meters with percent of span bar
- Optional display mode indicates the echo signal return curve
- Auto-temperature compensation for accurate measurement
- Fail-safe diagnostics with selectable signal fail-safe outputs
- Recognition, storage and rejection of false echo signal returns
- IP67 stainless enclosure with polycarbonate display window
