FLOWLINE LZ12 Vibration Liquid Level Switch
Submersible Ryton® sensor with polypropylene cable for corrosive liquids
Maintenance alarm proactively alerts user if sensor cleaning is required
|
Series |
LZ12 |
|
Type |
Vibration switch |
|
Classification |
General purpose |
|
Application |
Wastewater |
|
Function |
Level switch |
|
Max. length |
— |
|
Supply |
12-36 VDC |
|
Contact |
(1) SPST relay |
|
Rating |
60 VA (1A max) |
|
Enclosure |
NEMA 6 (IP68) |
|
Termination |
Cable |
|
Mount |
3/4″ NPT (G) |
|
Temperature |
-40º F. (-40º C.) to 176º F. (80º C.) |
|
Max. pressure |
150 PSI (10 bar) |
|
Material |
PP-Ryton |
lAutomatic coating adjustment optimizes sensor performance
lSubmersible Ryton® sensor with polypropylene cable for corrosive liquids
lMaintenance alarm proactively alerts user if sensor cleaning is required
l60VA SPST relay selectable NO or NC via power supply wiring polarity
lCompatible with Smart Trak and Switch-Pak installation fittings
