FLOWLINE DL24 Multi-Function Ultrasonic Liquid Level Sensor
Configuration is fast and easy via WebCal software and USB adapter
Narrow 2” beam width and short 4” dead band optimized for small tanks
|
Classification |
General purpose |
|
Media |
Liquids |
|
Application |
Day tank, skid or machine |
|
Condensation |
Minimal |
|
Range |
9.8' (3m) |
|
Output |
4-20 mA + (4) SPST relays |
|
Display |
No |
|
Configuration |
WebCal software |
|
Termination |
Cable |
|
Mount |
1" NPT (G) |
|
Temperature |
20º F. (-7º C.) to 140º F. (60º C.) |
|
Max. pressure |
30 PSI (2 bar) |
|
Trans. material |
PVDF |
lLevel measurement, switch and control functions up to 9.8’ (3m)
lConfiguration is fast and easy via WebCal software and USB adapter
lNarrow 2” beam width and short 4” dead band optimized for small tanks
lFour programmable relays for switch, pump or valve control and fail-safety
n1 pump or valve with 3 alarms
n2 pumps lead-lag with 2 alarms
n2 pumps duplexing with 2 alarms
n4 independent switch point alarms
lPVDF transducer and 6P polycarbonate enclosure for corrosive liquids
lAutomatic temperature compensation for accurate measurement
